We’ve been blown away by the amount of interest we’ve already had in our new gravel frame the Mehteh. You can now pre-order the Mehteh HERE and we should be shipping these out to customers in late September.
Ahead of this we thought we’d release further info on the frame so people can start planning their builds. If you’re interested in getting a Mehteh sign up to our newsletter and you’ll be one of the first to know when it’s available:
Frame Spec:
- Frame Tubing: Reynolds 725 heat treated chromoly double-butted main triangle, ED coated
- Fork: 1.5″ – 1.1/8″ tapered steerer carbon/alloy disc fork, mudguard mounts. 15x100mm TA (included)
- Full-length cable housing guides for derailleurs and brakes
- Stealth dropper post routing (not pictured on prototype)
- 3 sets bottle cage mounts on all sizes
- Rear rack and mudguard mounts
- Brake compatibility: Flat mount, 160mm rotor
- Rear Dropouts: 12x142mm TA (included)
- Seat post diameter: 27.2mm
- Seat clamp diameter: 30mm (included)
- Headset: 44mm, SHIS ZS44/28.6 upper, EC44/40 lower (not included)
- Front derailleur clamp diameter: 28.6 mm
- Bottom bracket shell: 68mm bottom bracket, ISO threaded
- Maximum tyre clearance: 700c x 45mm, 650b x 56mm
- Chainring clearance: up to 52-39-30t triple, 50-34t double, 48t single
Geometry:
Size | X-Small | Small | Medium | Large | X-Large |
Stack | 545mm | 561mm | 577mm | 596mm | 615mm |
Reach | 369mm | 378mm | 385mm | 394mm | 403mm |
Seat Tube (C-T) | 490mm | 510mm | 530mm | 550mm | 570mm |
Top Tube (C-C) | 510mm | 527mm | 543mm | 558mm | 573mm |
Top Tube (Effective) | 525mm | 544mm | 561mm | 576mm | 591mm |
Head Tube | 110mm | 125mm | 140mm | 160mm | 180mm |
Head Angle | 70.5 | 71 | 71.5 | 71.5 | 71.5 |
Seat Angle | 74 | 73.5 | 73 | 73 | 73 |
BB Drop | 70mm | 70mm | 70mm | 70mm | 70mm |
Chainstay Length | 430mm | 430mm | 430mm | 430mm | 430mm |
Fork Length (A-C) | 400mm | 400mm | 400mm | 400mm | 400mm |
Fork Rake | 45mm | 45mm | 45mm | 45mm | 45mm |
Wheelbase | 1009mm | 1019mm | 1026mm | 1042mm | 1057mm |
